5 Repairing the Fluorescence Detector
5
Insert the new or cleaned condenser, shift it completely
to its mechanical stop and fit the screw.
6 Replace the lamp housing cover and fix the screws.
Carefully insert the rear foam. Reconnect the
monochromator cables to the main board. Left is
excitation, right is emission.
Next Steps:
• Replace the covers as described in “Replacing the Foam and the Top Cover” on page 149.
• Re-install the detector in the stack.
• Enter the replacement of the lamp in the maintenance logbook (this will reset the lamp counter).
• Turn the lamp on.
• Perform a wavelength verification to check the correct positioning of the replaced assemblies, as described in chapter
“Wavelength Verification and Calibration" on page 101.
A
B
A
B
A
Rear
foam
EM
EX
