Agilent Technologies 1100 Series Reference Manual

Repairing the Fluorescence Detector 5
1100 Series FD Reference Manual 153
2
Carefully remove the rear foam. 3 Using the 4 mm hexagonal key, unscrew the five screws,
remove the cover and place it on the bench without
turning it around.
Note:
DO NOT unscrew the grounding screw (marked with
X)
4 Using a 2.5 mm hexagonal key, loosen the screw and
remove the condenser. There is a mechanical stop for the
condenser.
A
B
A
B
A
Rear
foam
A
B
A
B
A
