Agilent Technologies 1100 Series Reference Manual

226 1100 Series FD Reference Manual
6 Identifying Parts and Materials
Agilent 1100 to 3396 Series III / 3395B Integrators
Tabl e 45
Connector
03396-61010
Pin
33XX
Pin
Agilent 1100
Signal Name Active
(TTL)
9 1 - White Digital ground
NC 2 - Brown Prepare run Low
3 3 - Gray Start Low
NC 4 - Blue Shut down Low
NC 5 - Pink Not connected
NC 6 - Yellow Power on High
14 7 - Red Ready High
4 8 - Green Stop Low
NC 9 - Black Start request Low
13, 15 Not connected
