230 1100 Series FD Reference Manual
6 Identifying Parts and Materials
Agilent 1100 to 3396 Integrators
Tabl e 50
Connector
03396-60560
Pin
3392/3
Pin
Agilent 1100
Signal Name BCD Digit
11BCD 520
22BCD 780
33BCD 640
44BCD 410
55BCD01
66BCD 38
7 7 BCD 2 4
88BCD 12
9 9 Digital ground
NC 15 + 5 V Low
