Agilent Technologies 93000 SOC Series User Manual

Lesson 2 – Addressing the Analog Modules
137
Time Interval Analyzer
The Time Interval Analyzer (TIA) can measure a time interval for
7 input channels. In addition, two lines TRIG1 and TRIG2 are
available to provide external arming signals to the TIA:
GND1-7: Ground of each input is separated from other inputs to reduce noise to AWG and digitizer.
Pin No
GND
Pin TIA
1 DGND TRIG2
2 DGND TRIG1
3GND7LOOPBACK-7
4GND7INPUT-7
5GND6LOOPBACK-6
6GND6INPUT-6
7GND5LOOPBACK-5
8GND5INPUT-5
9GND4LOOPBACK-4
10 GND4 INPUT-4
11 GND3 LOOPBACK-3
12 GND3 INPUT-3
13 GND2 LOOPBACK-2
14 GND2 INPUT-2
15 GND1 LOOPBACK-1
16 GND1 INPUT-1
17
