Lesson 7 – Executing the DAC Distortion Test

286

The INFO column shows the type and origin of the resulting

harmonic frequencies. The harmonics for two fundamentals are

calculated according to:

Harmonics Calculation for 2 Fundamentals

Abbrev. Meaning Formula for 2 Fundamentals

F Fundamentals (generated

signal frequencies)

F1 , F2

D 2 2nd order distortion 2 * F1 , 2 * F2

D 3 3rd order distortion 3 * F1 , 3 * F2

I 2 2nd order intermodulation | F1 ± F2 |

I 3 3rd order intermodulation | F1 ± 2 * F2 |, | 2 * F1 ± F2 |
