Configuring Dynamic Link Aggregation Application Examples
OmniSwitch 6800/6850/9000 Network Configuration Guide March 2008 page 17-31
Link Aggregation and QoS Example
As shown in the figure on page 17-29, VLAN 12, which uses 802.1Q frame tagging and 802.1p prioritiza-
tion, has been configured to use dynamic aggregate group 7. The actual physical links connect ports 4/1,
4/2, 4/3, and 4/4 on Switch A to ports 1/1, 1/2, 1/3, and 1/4 on Switch C (a stack of four OmniSwitch 6800
Series switches). Follow the steps below to configure this network:
Note. Only the steps to configure the local (i.e., Switch A) switch are provided here since the steps to
configure the remote (i.e., Switch C) switch would not be significantly different.
1 Configure dynamic aggregate group 7 by entering:
-> lacp linkagg 7 size 4
2 Configure ports 4/1, 4/2, 4/3, and 4/4 the same actor administrative key (7) by entering:
-> lacp agg 4/1 actor admin key 7
-> lacp agg 4/2 actor admin key 7
-> lacp agg 4/3 actor admin key 7
-> lacp agg 4/4 actor admin key 7
3 Create VLAN 12 by entering:
-> vlan 12
4 Configure 802.1Q tagging with a tagging ID (i.e., VLAN ID) of 12 on dynamic aggregate group 7 by
entering:
-> vlan 12 802.1q 7
5 If the QoS Manager has been disabled (it is enabled by default) enable it by entering:
-> qos enable
Note. Optional. Use the show qos config command to determine if the QoS Manager is enabled or
disabled.
6 Configure a policy condition for VLAN 12 called “vlan12_condition” by entering:
-> policy condition vlan12_condition destination vlan 12
7 Configure an 802.1p policy action with the highest priority possible (i.e., 7) for VLAN 12 called
“vlan12_action” by entering:
-> policy action vlan12_action 802.1P 7
8 Configure a QoS rule called “vlan12_rule” by using the policy condition and policy rules you config-
ured in steps 8 and 9 above by entering:
-> policy rule vlan12_rule enable condition vlan12_condition action
vlan12_action
9 Enable your 802.1p QoS settings by entering qos apply as shown below:
-> qos apply
