Action Combinations Configuring QoS
page 30-8 OmniSwitch 6800/6850/9000 Network Configuration Guide March 2008
Action Combinations
The CLI prevents you from configuring invalid action combinations that are never allowed; however, it
does allow you to create combinations that are supported in some scenarios. For example, an action speci-
fying maximum bandwidth may be combined with an action specifying priority.
The following actions are supported and may be combined with other actions:
• ACL (disposition drop)
• Priority
• 802.1p ToS/DCSP Stamping and Mapping
• Maximum Bandwidth
• Port Redirection (not supported on the OmniSwitch 6800)
• Link Aggregate Redirection (not supported on the OmniSwitch 6800 and 6850)
• Port Disable (not supported on the OmniSwitch 6800)
• Permanent Gateway IP (not supported on the OmniSwitch 6800 and 6850)
• Mirror (not supported on the OmniSwitch 6800)
Use the following policy action combinations table as a guide when creating policy rules. For more infor-
mation about combining policy conditions or policy conditions and actions, see “Condition Combina-
tions” on page 30-6 and “Condition and Action Combinations” on page 30-9.
Note that the minimum bandwidth action is not included in the list of actions because it is no longer
supported on the OmniSwitch 6800 and is not supported on the OmniSwitch 6850 or 9000.
Policy Action Combinations Table
Drop Priority
Stamp/
Map Max BW
Redirect
Port
Redirect
Linkagg
Port
Disable
Permanent
Gateway IP Mirror
Drop
N/ANoNoNoNoNoNoNo Yes
Priority
No N/A Yes Yes Yes Yes No Yes Yes
Stamp/Map
No Yes N/A Yes Yes Yes No Yes Yes
Max BW
No Yes Yes N/A Yes Yes No Yes Yes
Redirect
Port
No Yes Yes Yes N /A No No Yes Yes
Redirect
Linkagg
No Yes Yes Yes N o N/A N o Yes Ye s
Port Disable
No No No No No No N/A No No
Permanent
Gateway IP
No Yes Yes Yes Ye s Ye s N o N/A Yes
Mirroring
Yes Yes Yes Yes Ye s Ye s N o Yes N /A
