ANATEL A643a User Manual

102 of 220 Anatel A643a Alarms - Anatel A643a
RPS - June 2007 - Edition 12
Operator Manual Anatel
To access the Analyzer’s Alarm Setup parameters:
1) With the desired Analyzer selected in any View, press the Setup Key to display its
menu selections.
2) Use the Up and Down Keys to specify Sensor Setup.
3) Press Enter to display the Sensor Setup Menu.
4) Similarly specify and select Analysis Setup.
5) Specify and select More Setup.
6) Specify and select Alarm Setup to display its submenu.
X
Sensor Setup:
System Setup:
C80 Setup:
Gateway Setup:
Fig 7-2 : Alarm Setup Menu
X
Analysis Setup:
Display/Print:
Sensor Name:
Diagnostics:
Fig 7-3 : Sensor Setup Menu
1 SENSOR NAME
Times & Cycle:
Analog Setup:
X
More Setup:
Fig 7-4 : Analysis Setup Menu
1 SENSOR NAME
X Alarm Setup:
Valve & Default:
Cell Setup
Fig 7-5 : More Setup Menu

ANATEL A643a Specifications

General

Brand	ANATEL
Model	A643a
Category	Measuring Instruments
Language	English
