74 of 220 Anatel A643a Setup - Anatel A643a
RPS - June 2007 - Edition 12
Operator Manual Anatel
• Timed generates a printout at the specified interval (Default: 1 Minute).
• Paper Saver generates a printout when the difference in conductivity values
between the current and the previous analysis cycle exceeds a specified
percentage. If chosen, this % Change in data must be specified (Default:
1 percent).
• Disabled inhibits all printouts. This option can be used in conjunction with the
Cycle Mode TOC & Purge setting (see “Purge Printouts” on page 72) to limit
printouts to TOC data (Default: Off).
8) Press Enter to select the specified format. A flashing cursor highlights the current
value.
Timed Purge Print
If Timed Purge Print is selected, a flashing block cursor highlights the minutes division.
9) Use the Up and Down Keys to specify the time division to be changed.
10) Press Enter to enable the Controller’s Edit Mode and the flashing block becomes an
underscore.
11) Use the Up and Down Keys to scroll until the desired period is displayed.
12) Press eto save the setting.
13) Repeat the editing process with each time division until the entire Print Interval has
been entered into the display.
14) Press Esc repeatedly to exit this function and return to the normal display.
Fig 5-40 : Timed Purge Print Screen
1 SENSOR NAME
Printer Interval
00:05:00 h:mm:ss
S/T to change
Fig 5-41 : Timed Purge Print
