196 of 220 Specifications and Accessories - Anatel A643a
RPS - June 2007 - Edition 12
Operator Manual Anatel
Fig B-3 : C80 Controller
Displays
Main: 4-line x 16-character Super-Twist LCD
Channel: 8 Bi-color (red/green) LEDs
Physical
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Maximum Relative Humidity: 90% RH
Maximum Altitude: 4,000 m (13,125 ft)
Power: 9 VDC Power Pack
(120 VAC ±10%, 60 Hz standard,
230 VAC ±10%, 50 Hz optional)
Power Consumption: 7.6 W max.
Case: ABS front panel with Lexan overlay
Size: 120 mm L x 81 mm W x 48 mm D
(4.7” L x 3.2” W x 1.9”D)
2.5” total depth behind panel
(allow 4–5” to avoid crimping)
Weight: 0.75 kg (1.5 lb)
Mounting: Panel
Connections
Communications: Shielded Twin-axial, Twist-Lock BNC
