Two TOC Print intervals are available. Continuous generates a TOC printout at the
conclusion of each analysis; Paper Saver triggers a printout only when the change in TOC
level between analyses exceeds a userdefined percentage.
To set the instrument’s TOC Print interval:
1) With the desired Analyzer selected in any View, press the Setup Key to display its
submenu.
2) Use the Up and Down Keys to specify Sensor Setup.
3) Press Enter to access it submenu.
4) Specify Display/Print and press Enter.
5) Select Printer Setup from the Display/Print menu and press Enter.
6) Specify TOC Print and press Enter.
TREND [PPB/HR]
The TOC directional trend in ppb over the last hour.
COND (or RESIS)
The conductivity (or resistivity) of the sample if it is temperature-uncompensated.
TEMP
The temperature of the sample.
CRV TYP
The profile type of the sample.
Fig 5-33 : Auto TOC Printout
1 SENSOR NAME
X TOC Print:
Purge Print:
Fig 5-34 : TOC Print
Table 5-2 :
TOC Printout Information (Continued)
Sensor
