Anatel A643a - Anatel A643a Setup 75 of 220
RPS - June 2007 - Edition 12
Anatel Operator Manual
Paper Saver Purge Print
If Paper Saver Purge Print is selected, a flashing cursor underscores the second digit of the
setting.
9) Use the Up and Down Keys to scroll the value until the desired percentage is
displayed.
10) Press Esc repeatedly to exit this function and return to the normal display.
5.7 The Manual Mode
Analysis and reporting functions are continuous when the Anatel A643a is in the Auto TOC
Mode. There are times, however, when manual control over the instrument’s analysis is
desirable. The Manual Samples menu selection allows the user to conduct a single sample
analysis when necessary.
The Manual Mode is used to interrupt the current analysis in order to start a new analysis. It is
convenient for initiating a manual analysis during Anatel A643a installation, or to synchronize
analysis with process equipment (sampling is under user control). Manual samples also may
be acquired online from the water system or off-line from a sample vial (grab sample).
Access to the Analyzer by other connected C80 Controllers is denied while the instrument is in
the Manual Sample or Oxidation State. Access is restored when the Manual Mode is exited.
Fig 5-42 : Paper Saver Print Screen
1 SENSOR NAME
% Change in data
10 percent
S/T to change
Fig 5-43 : Paper Saver Print
To Next Page
