124 of 220 Analog Outputs - Anatel A643a
RPS - June 2007 - Edition 12
Operator Manual Anatel
4) Specify Analysis Setup and then press Enter to access its submenu.
5) Specify Analog Setup and press Enter to display its parameter options.
9.2.2.1 DAC Range Settings
The DAC Range Menu provides access to the Analyzer’s analog output range as well as its
zero-scale and full-scale settings.
To display the DAC Range Menu:
1) With the Analog Setup Menu displayed, specify DAC Range and then press Enter to
display its available menu selections.
X
Analysis Setup:
Display/Print:
Sensor Name
Diagnostics:
Fig 9-4 : Sensor Setup Menu
1 SENSOR NAME
X DAC Range:
Ext DAC Module:
DAC Modes:
Fig 9-5 : Analog Setup
DAC Range Sets the Analyzer’s internal, and external, analog output range as
4-20 mA or 0–20 mA (see “Analog Output Range” on page 125).
The limits of this range correspond to the zero-scale and full-scale
values entered for TOC, conductivity or resistivity, and
temperature (“TOC Output Range” on page 126).
Ext DAC
Module
Enables the output to an External DAC Module (“Optional
Conductivity/Resistivity & Temperature Outputs” on page 129).
DAC Modes Allows access to the DAC Error Output and DAC Calibration
Output settings (“DAC Error Output” on page 128).
1 SENSOR NAME
X DAC mA Range:
DAC Zero-Scale:
DAC Full-Scale:
Fig 9-6 : DAC Range Menu
To Next Page
