ANATEL A643a User Manual

Anatel A643a - Specifications and Accessories 195 of 220
RPS - June 2007 - Edition 12
Anatel Operator Manual
B.1.3 C80 Controller
Note:
P/N FG1000201 (120 VAC, 60 Hz)
P/N FG1000301 (230 VAC, 50 Hz)
The Model C80 Controller provides multiple Sensor display, individual instrument setup,
system alarm indication and printer control functions for up to 8 Sensors via an RS-485
Network.
Analysis Cell Volume: 0.4 mL
Power: 100 to 240 VAC ±10%, 50/60 Hz
Power Consumption: 2 Amps max. @ 120 VAC,
1 Amp max. @ 230 VAC
Fuse: 3 Amp, 250 VAC Fast-Blow
Power Cord:
100 to 120 VAC Main:
208 to 230 VAC Main —
Rating: 125 VAC, 10 Amp
Foil Shield 100%, Braid Shield 85%
Connectors: IEC 320–C13 and NEMA 5–15P
Rating: 250 VAC, 10 Amp
Foil Shield 100%, Braid Shield 85%
Connectors: IEC 320–C13 and CEE 7/7 or CEI 23–16/VII
(or like, depending on country)
I/O Connections
Analog: Opto-isolated 4-20 mA output
Non-isolated 12 VDC output @ 1/2 Amp max.
Digital I/O: Two opto-isolated inputs
Two opto-isolated outputs
Serial Interfaces: RS485 opto-isolated Network
RS232 Data Acquisition
RS232 Printer
RS232 Diagnostics
Physical
