ANATEL A643a - Auto TOC Printout; Fig 5-32: Sample TOC Printout

Anatel A643a - Anatel A643a Setup 69 of 220
RPS - June 2007 - Edition 12
Anatel Operator Manual
5.5.2 Auto TOC Printout
Note:
Default: Continuous
The TOC printout furnishes the following Anatel A643a Analyzer information:
Fig 5-32 : Sample TOC Printout
Table 5-2 :
TOC Printout Information
Sensor
The Model Number of the instrument.
SN
The Serial Number of the instrument.
ID
Its Channel ID Number.
Name
The user-entered name of the instrument.
TOC LIMIT
The instrument’s set TOC alarm limit.
SAMPLE TIME The instrument’s set Sample Time.
CYCLE TIME The instrument’s set Cycle Time.
Data
The Current Date.
TIME
The time when the sample was captured.
TOC [PPB]
The measured TOC of the sample in parts per billion.
%AL The current TOC value as a percentage of its set Alarm Limit.
