ANATEL A643a User Manual

Anatel A643a - Specifications and Accessories 191 of 220
RPS - June 2007 - Edition 12
Anatel Operator Manual
Appendix B: Specifications and Accessories
B.1 Performance Specifications
The Anatel A643a TOC Analyzer is specifically designed for use in applications that monitor
ultrapure water with a typical conductivity less than 0.2 microsiemens/cm (as high as 5.0 µS/
cm for pH neutral waters) compensated to 25 °C.
At a minimum, the Anatel A643a System consists of a single Analyzer and a C80 Controller.
The maximum configuration may contain up to 8 Analyzers and 8 Controllers in addition to a
host computer and associated input/output devices.
Note:
Anatel A643a Specifications are subject to change without notice.
PERFORMANCE
Note:
† Repeatability of reading on an individual instrument.
** Sample water temperature specification stated without external heat exhanger. For sample
water over 65 °C a CX-20 heat exchanger is highly recommended.
TOC Mode
Operating Range: 1 to 1000 ppb as carbon
Resistivity: 0.01 to 18.2 M.-cm
Conductivity: 0.05 to 150 µS/cm (@ 25 °C)
Display Resolution: 1 ppb
Online Repeatability†: ±1% or 1ppb (whichever is greater)
Maximum Input Conductivity: 0.2 µS/cm for all waters
1.0 µS/cm for all neutral waters
5 µS/cm for water with
CO
2
as the sole conductive species
Ambient Operating Temperature:
Anatel A643a–S Analyzer:
Anatel A643a–P Analyzer:
15 °C to 40 °C (59 °F to 104 °F)
15 °C to 35 °C (59 °F to 95 °F)
Sample Water Temperature: 5 °C to 65 °C (41 °F to 149 °F)**
Sample Inlet Flow Rate: 60 mL/min to 300 mL/min
Sample Inlet Pressure: 10 psi to 100 psi (69 to 690 kPa)
