12.3.3 Data Read Commands
The Data Read functions return multiple values, the string terminated with a <cr><lf>.
Note:
If the Anatel A643a Analyzer is in an operational mode that does not generate a TOC result
(modes 6 through 12), the TOC, TOC Alarm Percentage, TOC Trend, Profile (Curve) Type and
Oxidation Time are not returned.
Note:
Data normally is returned only in response to issuance of the RD or RE commands. When
collecting data with a serial communications program such as Windows 95 Hyperterminal,
however, it is more convenient to have the data displayed automatically. This can be done
using the SA command, which then displays data whenever they are reported.
20mA Output On Alarm (0 = minimum value,
1 = unchanged, 2 = maximum value)
9.2.2.4
TOC Mode Paper Saver Percentage Change (1–99) 5.5.2
Purge Mode Paper Saver Percentage Change (1–99) 5.6.1
Purge Mode Interval Between Printouts (hh:mm:ss) 5.6.1
Zero-Scale TOC Range (ppb) 9.2.2.3
Full-Scale TOC Range (ppb) 9.2.2.3
User TOC Calibration Slope (Read-Only)
External DAC Zero-Scale Conductivity/Resistivity Range
(Units depend on Conductivity/Resistivity Units of Measure) 9.3.2.3
External DAC Full-Scale Conductivity/Resistivity Range
(Units depend on Conductivity/Resistivity Units of Measure) 9.3.2.3
External DAC Zero-Scale Temperature Range (°C) 9.3.2.4
External DAC Full-Scale Temperature Range (°C) 9.3.2.4
Digital Control (0 = disabled, 1 = enabled) 10.2
Log (0 = Data & Audit, 1 = Audit Only) 8.3.1
User Conductivity Calibration Slope (Read-Only)
Example: "HR 00:01:00 00:00:00 500 0 0 1
SENSOR_NAME 0 0 0 0 0 0 0 0 0 0 1 1 00:01:00
0 1000 1.0 0 20 5 95 0 1.0 <cr>"
SY Set Time (MM:DD:YY:hh:mm:ss format) 2.2.3.1
Example: "SY 03 04 1993 12 33 00 <cr>"
Table 12-2 :
