Anatel A643a - Printer Output 113 of 220
RPS - June 2007 - Edition 12
Anatel Operator Manual
To change any of these settings:
1) Turn the printer power switch OFF.
2) Restore power while pressing the ONLINE button. Release the button when a printout
of the current settings begins.
3) Push the ONLINE button once again and DIP SW1 is printed, prompting for changes
on switches 1–8.
4) Enter the settings for DIP Switch 1 by pressing ONLINE for On (enabled) and FEED
for Off (disabled) for each of the switches 1–8 in succession. The ONLINE LED
illuminates to indicate an “On” entry: the OFFLINE LED correspondingly indicates an
“Off” entry.
Be sure to enter a setting for all eight switches because this setup mode cannot be cancelled
once initiated.
DIP Switch 2
Switch Setting Function
1 On 40-Column Printing
2 On Backup Font Enabled
3 On Normal Characters
4 Off Zero = Slash
5 On International Character Set = USA
6 On International Character Set = USA
7 On International Character Set = USA
8 Off International Character Set = USA
DIP Switch 3
Switch Setting Function
1 On 8 Data Bits
2 On No Parity Setting
3 Off Even Parity
4 On Flow Control (XON/XOFF)
5 On 1200 Baud
6 Off 1200 Baud
7 On 1200 Baud
8 Off 1200 Baud
Table 8-1 :
Preset DIP Switches (Continued)
