All of these variables, default or user-entered, are stored in battery-backed memory within
each Analyzer to avoid loss when the instrument is powered down. A 10–Bad Config code
is reported (see “Alarm Codes” on page 175) if a bad battery corrupts these values. In this
instance, the default parameters must be restored and then modified as necessary.
Note:
This procedure restores all Analyzer parameters to their factory default values except
customer calibrations, which are not affected.
Outputs
mA Range: 4 to 20mA
TOC Zero-Scale: 0 ppb
TOC Full-Scale: 1000 ppb
Conductivity Zero-Scale: 0 µS/cm U
Conductivity Full-Scale: 20 µS/cm U
Temperature Zero-Scale: 5 °C
Temperature Full-Scale: 95 °C
Activate External DAC: No (Inactive)
DAC Error Output: Minimum Output
DAC Calibration Output: Inactive
Digital Control: Disabled
Active Alarm Setup: TOC Alarm
TOC Alarm Limit: 0500 ppb
Alarm Beeper: Enabled
Supervisor & Operator Passwords: 00000 (Disabled)
Resistivity/Conductivity Units: cm U / µS
Log Setup: Data & Audit
TOC Print Interval: Continuous
% Change in TOC 1 percent
Cycle Mode: TOC & Idle
Purge Print Interval: Timed
Print Interval: 00:01:00 (hh:mm:ss)
% Change in Resistivity: 1 percent
Table 5-1 :
Factory Defaults (Continued)
