Sheet #607u – ATR 0 – 1 – 2 – 3 function
Version 1.04a User guide ATEQ 6th series Page 6/6
It's possible to check the recorded parameters
by the special cycle by pressing the
key just after the special cycle end.
Note: it's possible to modify these parameters.
T(70%6%*'%-6'5
Ź Measure : 90.0
Max value : 100.0
% Drift : 20
CheckTime : 5.0 s
At each test time the device displays the
"
ATR MODE" message to inform the ATR
computing of the device.
600.0
mbar
TEST
050
Pa
ATR MODE
Pr1 1.4 s
If theATR special cycle is not carried out
before, the alarm message
"
Do Learning Cycle ATR" is triggered.
0.0
mbar
ALARM
Do Learning Cycle
ATR
Pr1 READY
