495

8331B–AVR–03/12

Atmel AVR XMEGA AU

Figure 36-53. Autorefresh between two accesses

* The number of NOPs is equal to RPDLY[1:0] (RPDLY = 1 is shown)

** The number of NOPs is equal to ESRDLY[2:0] (ESRDLY = 1 is shown)

Auto Refresh

Autorefresh between two acesses

Precharge All

Active

NOP*

CLK

CKE

CAS

RAS

DQM

BA[1:0]

A[11:0]

Clk

PER2
