• Bit 6:2 – PSADIV[4:0]: Prescaler A Division Factor
These bits define the division ratio of the clock prescaler A according to Table 7-2. These bits
can be written at run-time to change the frequency of the Clk
PER4
clock relative to the system
clock, Clk
SYS
.
• Bit 1:0 – PSBCDIV: Prescaler B and C Division Factors
These bits define the division ratio of the clock prescalers B and C according to Table 7-3. Pres-
caler B will set the clock frequency for the Clk
PER2
clock relative to the Clk
PER4
clock. Prescaler C
will set the clock frequency for the Clk
PER
and Clk
CPU
clocks relative to the Clk
PER2
clock. Refer
to Figure 7-5 on page 88 fore more details.
Table 7-2. Prescaler A division factor.
PSADIV[4:0] Group Configuration Description
00000 1 No division
00001 2 Divide by 2
00011 4 Divide by 4
00101 8 Divide by 8
00111 16 Divide by 16
01001 32 Divide by 32
01011 64 Divide by 64
01101 128 Divide by 128
01111 256 Divide by 256
10001 512 Divide by 512
10101 Reserved
10111 Reserved
11001 Reserved
11011 Reserved
11101 Reserved
11111 Reserved
Table 7-3. Prescaler B and C division factors.
PSBCDIV[1:0] Group Configuration Prescaler B division Prescaler C division
00 1_1 No division No division
01 1_2 No division Divide by 2
10 4_1 Divide by 4 No division
11 2_2 Divide by 2 Divide by 2
