Page 4–78
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Chapter 4: AC Drive Parameters
Type Hex Addr Dec Addr
P3.21
Multi-Function Output Terminal 5
(option card DO10 or RO10) or (PLC Y5)
♦R/W 0315 40790
Range/Units (Format: 16-bit unsigned) Default
Same as P3�17~P3�31 (page 4–74)
0
This parameter sets the function of Multi-Function Output Terminal 5 (DO10) or (RO10) (option
card), and can be used only after installing the optional card.
DO10 can be wired for a sink or source configuration, and is located on the GS4-06CDD expansion
card.
RO10 has a normally open dry contact located on the GS4-06TR expansion card.
•
Represented by Bit 5 on the “DO Status” (P3�47) bit map�
•
NO/NC behavior is controlled by Bit 5 in P3�43�
Type Hex Addr Dec Addr
P3.22
Multi-Function Output Terminal 6
(option card DO11 or RO11) or (PLC Y6)
♦R/W 0316 40791
Range/Units (Format: 16-bit unsigned) Default
Same as P3�17~P3�31 (page 4–74)
0
This parameter sets the function of Multi-Function Output Terminal 6 (DO11) or (RO11) (option
card), and can be used only after installing the optional card.
DO11 can be wired for a sink or source configuration; located on the GS4-06CDD expansion card.
RO11 has a normally open dry contact located on the GS4-06TR expansion card.
•
Represented by Bit 6 on the “DO Status” (P3�47) bit map�
•
NO/NC behavior is controlled by Bit 6 in P3�43�
Type Hex Addr Dec Addr
P3.23 Multi-Function Output Terminal 7 (option card RO12) or (PLC Y7)
♦R/W 0317 40792
Range/Units (Format: 16-bit unsigned) Default
Same as P3�17~P3�31 (page 4–74)
0
This parameter sets the function of Multi-Function Output Terminal 7 (RO12) (option card), and
can be used only after installing the optional card.
RO12 has a normally open dry contact located on the GS4-06TR expansion card.
•
Represented by Bit 7 on the “DO Status” (P3�47) bit map�
•
NO/NC behavior is controlled by Bit 7 in P3�43�
Type Hex Addr Dec Addr
P3.24 Multi-Function Output Terminal 8 (option card RO13) or (PLC Y10)
♦R/W 0318 40793
Range/Units (Format: 16-bit unsigned) Default
Same as P3�17~P3�31 (page 4–74)
0
This parameter sets the function of Multi-Function Output Terminal 8 (RO13) (option card), and
can be used only after installing the optional card.
RO13 has a normally open dry contact located on the GS4-06TR expansion card.
•
Represented by Bit 8 on the “DO Status” (P3�47) bit map�
•
NO/NC behavior is controlled by Bit 8 in P3�43�
