Chapter 4: AC Drive Parameters
Page 4–79
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Type Hex Addr Dec Addr
P3.25 Multi-Function Output Terminal 9 (option card RO14) or (PLC Y11)
♦R/W 0319 40794
Range/Units (Format: 16-bit unsigned) Default
Same as P3�17~P3�31 (page 4–74)
0
This parameter sets the function of Multi-Function Output Terminal 9 (RO14) (option card), and
can be used only after installing the optional card.
RO14 has a normally open dry contact located on the GS4-06TR expansion card.
•
Represented by Bit 9 on the “DO Status” (P3�47) bit map�
•
NO/NC behavior is controlled by Bit 9 in P3�43�
Type Hex Addr Dec Addr
P3.26 Multi-Function Output Terminal 10 (option card RO15) or (PLC Y12)
♦R/W 031A 40795
Range/Units (Format: 16-bit unsigned) Default
Same as P3�17~P3�31 (page 4–74)
0
This parameter sets the function of Multi-Function Output Terminal 10 (RO15) (option card), and
can be used only after installing the optional card.
RO15 has a normally open dry contact located on the GS4-06TR expansion card.
•
Represented by Bit 10 on the “DO Status” (P3�47) bit map�
•
NO/NC behavior is controlled by Bit 10 in P3�43�
Type Hex Addr Dec Addr
P3.27 Multi-Function Virtual Output 11 (DO16) or (PLC Y13)
♦R/W 031B 40796
Range/Units (Format: 16-bit unsigned) Default
Same as P3�17~P3�31 (page 4–74)
0
This parameter sets the function of Multi-Function Virtual Output 11 (PLC DO16).
This output is a virtual terminal used by the PLC; there is no physical wiring point.
•
Represented by Bit 11 on the “DO Status” (P3�47) bit map�
•
NO/NC behavior is controlled by Bit 11 in P3�43�
Type Hex Addr Dec Addr
P3.28 Multi-Function Virtual Output 12 (DO17) or (PLC Y14)
♦R/W 031C 40797
Range/Units (Format: 16-bit unsigned) Default
Same as P3�17~P3�31 (page 4–74)
0
This parameter sets the function of Multi-Function Virtual Output 12 (PLC DO17).
This output is a virtual terminal used by the PLC; there is no physical wiring point.
•
Represented by Bit 12 on the “DO Status” (P3�47) bit map�
•
NO/NC behavior is controlled by Bit 12 in P3�43�
Type Hex Addr Dec Addr
P3.29 Multi-Function Virtual Output 13 (DO18) or (PLC Y15)
♦R/W 031D 40798
Range/Units (Format: 16-bit unsigned) Default
Same as P3�17~P3�31 (page 4–74)
0
This parameter sets the function of Multi-Function Virtual Output 13 (PLC DO18).
This output is a virtual terminal used by the PLC; there is no physical wiring point.
•
Represented by Bit 13 on the “DO Status” (P3�47) bit map�
•
NO/NC behavior is controlled by Bit 13 in P3�43�
