Page 4–80
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Chapter 4: AC Drive Parameters
Type Hex Addr Dec Addr
P3.30 Multi-Function Virtual Output 14 (DO19) or (PLC Y16)
♦R/W 031E 40799
Range/Units (Format: 16-bit unsigned) Default
Same as P3�17~P3�31 (page 4–74)
0
This parameter sets the function of Multi-Function Virtual Output 14 (PLC DO19).
This output is a virtual terminal used by the PLC; there is no physical wiring point.
•
Represented by Bit 14 on the “DO Status” (P3�47) bit map�
•
NO/NC behavior is controlled by Bit 14 in P3�43�
Type Hex Addr Dec Addr
P3.31 Multi-Function Virtual Output 15 (DO20) or (PLC Y20)
♦R/W 031F 40800
Range/Units (Format: 16-bit unsigned) Default
Same as P3�17~P3�31 (page 4–74)
0
This parameter sets the function of Multi-Function Virtual Output 15 (PLC DO20).
This output is a virtual terminal used by the PLC; there is no physical wiring point.
•
Represented by Bit 15 on the “DO Status” (P3�47) bit map�
•
NO/NC behavior is controlled by Bit 15 in P3�43�
