Chapter 4: AC Drive Parameters
Page 4–189
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Type Hex Addr Dec Addr
P9.64 Comm Card External Set
R/W 0940 42369
Range/Units (Format: 16-bit binary) Default
0, 2
Bit 0 = reserved
Bit 1 = Write Ethernet Parameters to the Comm Card
Bit 2 = reserved
0
The Ethernet communication cards have their own internal set of configuration registers. The
P9.xx parameters must be "pushed" into the Ethernet comm cards before they take effect.
Bit 1: Internet parameters enable
Set Bit 1 (enter a decimal value of 2) to write Ethernet-related parameter values into the comm
card after the comm card parameters have been set up in the GS4 drive. This bit will change to
0 when it finishes saving the update of internet parameters. If the value does not automatically
reset to 0 after entering "2" and pressing Enter, then the parameters did not get pushed down to
the comm card.
When comm card is reset to factory defaults, the P9 parameters still reside in the drive. Bit 1 must
be set high to write the Drive Parameters to the comm card.
For more detailed information, refer to Appendix B: Optional I/O and Communication Cards.
Type Hex Addr Dec Addr
P9.65 reserved
~ 0941 42370
P9.66 reserved
~ 0942 42371
P9.67 reserved
~ 0943 42372
P9.68 reserved
~ 0944 42373
Type Hex Addr Dec Addr
P9.69 Block Transfer Address Pointer 1
R/W 0945 42374
P9.70 Block Transfer Address Pointer 2
R/W 0946 42375
P9.71 Block Transfer Address Pointer 3
R/W 0947 42376
P9.72 Block Transfer Address Pointer 4
R/W 0948 42377
P9.73 Block Transfer Address Pointer 5
R/W 0949 42378
P9.74 Block Transfer Address Pointer 6
R/W 094A 42379
P9.75 Block Transfer Address Pointer 7
R/W 094B 42380
P9.76 Block Transfer Address Pointer 8
R/W 094C 42381
P9.77 Block Transfer Address Pointer 9
R/W 094D 42382
P9.78 Block Transfer Address Pointer 10
R/W 094E 42383
P9.79 Block Transfer Address Pointer 11
R/W 094F 42384
P9.80 Block Transfer Address Pointer 12
R/W 0950 42385
P9.81 Block Transfer Address Pointer 13
R/W 0951 42386
P9.82 Block Transfer Address Pointer 14
R/W 0952 42387
P9.83 Block Transfer Address Pointer 15
R/W 0953 42388
P9.84 Block Transfer Address Pointer 16
R/W 0954 42389
Range/Units (Format: 16-bit unsigned) Default
0~65535
0
This block of parameters (P9.69~P9.84) define the pointer addresses for Block Transfer. The actual
parameter data is read from and written into parameters P9.09~P9.24.
Refer to “Block Transfer Explanation” (page 4–192) for details about transferring blocks of data.
