89000109-002 xVue Touch Installation Manual
Rev 2 Page 5-4
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
13 KSD100_MAINT_ETH_RX_P In Included
14 KSD100_MAINT_ETH_RX_N In Included
15 AC_PWR_B1 PWR Included
16 AC_PWR_B2 PWR Included
17 AC_PWR_B3 PWR Included
18 AC_PWR_A1 PWR Included
19 AC_PWR_A2 PWR Included
20 AC_PWR_A3 PWR Included
21 VOR/ILS2_429_RX_B In Included
22 RADALT_A429_RX_A In Reserved
23 RADALT_A429_RX_B In Reserved
24 TRAFFIC_A429_TX_A Out Reserved
25 TRAFFIC_A429_TX_B Out Reserved
26 AFCS_KINGBUS_CLK_DI5VO In Reserved
27 AFCS_KINGBUS_DATA_DI5VO In Reserved
28 AFCS_KINGBUS_STROBE_DI5VO In Reserved
29 SXM_WX_RS422_RX_A In Reserved
30 SXM_WX_RS422_RX_B In Reserved
31 SXM_WX_RS422_TX_A Out Reserved
32 SXM_WX_RS422_TX_B Out Reserved
33 LIGHTNING_RS232_TX Out Reserved
34 SPARE_RS232_RX In Reserved
35 TRAFFIC_RS232_TX Out Reserved
36 TRAFFIC_RS232_RX In Reserved
37 AC_PWR_RTN3 GND Included
38 AC_PWR_RTN2 GND Included
39 AC_PWR_RTN1 GND Included
40 AC_DIMMING_BUS In Included
41 GS_FLAG_+_IN In Included
42 GS_FLAG_-_IN In Included
43 LOC_ENERGIZE_IN In Included
44 VOR_COMP_IN_HI In Included
45 VOR_COMP_IN_LO In Included
46 AUDIO_ALERTS_OUT Out Included
47 AUDIO_ALERTS_OUT_REF GND Included
48 GS_+_UP_IN In Included
J2 Pin Description I/O Initial Certification
