89000109-002 xVue Touch Installation Manual
Rev 2 Page 5-5
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
49 GS_+_DOWN_IN In Included
50 IFD1_ETH_RX_P In Reserved
51 IFD1_ETH_RX_N In Reserved
52 IFD2_ETH_RX_P In Reserved
53 IFD2_ETH_RX_N In Reserved
54 Spare GND GND Reserved
55 Spare GND GND Reserved
56 Spare GND GND Reserved
57 Spare GND GND Reserved
58 Spare GND GND Reserved
59 KSD100_CTRL_PANEL_PWR_RTN GND Included
60 NAV_DEV_+_RT_IN In Reserved
61 NAV_DEV_+_LT_IN In Reserved
62 NAV_FLAG_+_IN In Reserved
63 NAV_FLAG_-_IN In Reserved
64 APM_DATA_MISO In Included
65 APM_DATA_MOSI Out Included
66 APM_CLK Out Included
67 APM_DATA_CS_N Out Included
68 APM_WP_N Out Included
69 APM_PWR_3P3VDC PWR Included
70 APM_PWR_RTN GND Included
71 LIGHTNING_RS232_RX In Reserved
72 EIS_RS232_TX Out Reserved
73 EIS_RS232_RX In Reserved
74 KSD100_MAINT_RS232_TX Out Included
75 KSD100_MAINT_RS232_RX In Included
76 KSD100_CTRL_PANEL_RS232_TX Out Included
77 KSD100_CTRL_PANEL_RS232_RX In Included
78 KSD100_CTRL_PANEL_PWR_15VDC PWR Included
J2 Pin Description I/O Initial Certification
