149
> To remove, lift the embroidery module on the left and carefully pull to the left.
Preparing the embroidery hoop
The embroidery hoop consists of an outer and an inner hoop. There is a corresponding template for every
hoop. The embroidery area is marked in 1 cm squares. The center and end point are marked with holes. The
required marks can be transferred to the material.
> Mark the center of an embroidery motif on the fabric, using a water-soluble pen.
> Loosen the screw on the outer hoop.
> Remove the inner hoop.
> Make sure that the arrows marks of both hoops match.
> Attach the template holder.
> Place the template in the inner hoop, so the BERNINA logo is at the front edge at the arrow mark until it
clicks into place.
> Place the material under the inner hoop.
> Line up the marked center point on the center of the template.
035964.50.04_2014-08_Manual_B790_EN
