Preparation
44
> Select the previously attached the stitch plate .
– If the selected stitch plate is suitable in combination with the needle, sewing can be started.
– If the selected stitch plate is not suitable in combination with the needle, starting the machine is
automatically prevented.
2.10 Threading
Threading preparation
> Raise the needle.
> Raise the presser foot.
> Switch the machine off and disconnect it from the power supply system.
Threading the upper thread
> Place the foam pad on the spool holder.
> Place the thread spool on the spool holder so that the thread unwinds clockwise.
> Place the appropriate spool disc.
> Guide the thread in direction of the arrow through the rear thread guide and hold the thread with the
hands so that it is taut and can be inserted into the tension disc.
> Guide the thread in direction of the arrow through the tension disc.
> Pull the thread in direction of the arrow down (1) around the cover of the thread take-up lever (2).
> Guide the thread in direction of the arrow up (3) and insert it into the thread take-up lever.
035964.50.04_2014-08_Manual_B790_EN
