Bernina 790 - Threading the Triple Needle; Winding the Bobbin Thread

Preparation
48
Threading the triple needle
Always attach a foam pad when using the swiveling spool holder. This prevents the thread from getting
hooked at the spool holder.
Prerequisite:
• The triple needle is inserted.
> Place the foam pad, the thread spool and the appropriate spool disc on the spool holder.
> Place the filled bobbin on the swiveling spool holder.
> Add the appropriate spool disc.
> Place the thread spool.
> Thread the 3 threads up to the upper thread guide.
> Guide 2 threads past the thread tension discs on the left and to the thread guide above the needle (see
page 44).
> Guide 1 thread past the thread tension disc on the right and to the thread guide above the needle (see
page 44).
> Thread the first thread into the left needle manually.
> Thread the second thread into the center needle manually.
> Thread the third thread into the right needle manually (see page 47).
Winding the bobbin thread
The bobbin thread can be wound while sewing if the swiveling spool holder is used for winding.
> Place a foam pad on the spool holder.
> Place the thread spool on the spool holder.
> Add the appropriate thread disc on the spool holder.
> Attach the empty bobbin on the winding unit (1) so that the silvery sensor surface is down.
1
> Guide the thread in direction of the arrow into the rear thread guide (1).
> Guide the thread around the thread pretension clockwise (2).
