Preparation
39
> Push the slide-on table to the right until it engages.
> To remove the slide-on table, push the button down and pull the slide-on table to the left.
Attaching the seam guide
Prerequisite:
• The slide-on table is attached.
> Press the release button to insert the seam guide into the groove of the slide-on table from left or right.
2.6 Presser foot
Adjusting the presser position via the lever of the Free Hand System
> Adjust the sitting height so that the lever can be operated with the knee.
> Move the lever with the knee to the right to raise the presser foot.
– Simultaneously the feed dog is lowered and the thread tension is released.
> Release the lever slowly to lower the presser foot.
Adjusting the presser foot position via the button Presser foot up/down
> Press the button «Presser foot up/down» to raise the presser foot.
> Press the button «Presser foot up/down» again to lower the presser foot.
035964.50.04_2014-08_Manual_B790_EN
