Chroma Keyer
These settings are similar to the picture in picture keyer setting, however it applies to the
upstream keyer.
Drop with Transition Ties the upstream chroma keyer to the next transition and will
transition off screen when the next transition is performed.
Stay on with transition Holds the upstream chroma keyer on air so you can switch sources
without affecting the chroma key.
About Page
The about page tells you which version of ATEM software is installed on your computer.
To change the name of your ATEM Mini, click in the ‘label’ edit box, type in a new name and
click ‘save’
Setting up Open Broadcaster
Even though the ATEM Mini Pro and Extreme switcher models can stream directly using its
Ethernet connection, if you want to stream using an external computer then you can connect
the USB-C and it will appear as a webcam on your computer. This then lets you use streaming
software such as Open Broadcaster for streaming.
This section shows how to use Open Broadcaster to stream via the USB-C webcam output.
Open Broadcaster is an open source application that works as a streaming platform between
your ATEM Mini and your favorite streaming software like YouTube, Twitch, Facebook Live,
Vimeo Live and others. Open Broadcaster compresses your video to a bit rate that is easily
managed by your streaming app.
Below is a demonstration of how to set up Open Broadcaster to stream the webcam output
from your ATEM Mini using YouTube as the streaming application.
1 2
Launch Open Broadcaster and click on the plus
symbol in the ‘sources’ box.
Select ‘Video Capture Device’.
3 4
Name the new source and click ‘OK’. In the device menu, select Blackmagic Design
and click ‘OK’.
98Setting up Open Broadcaster
