Programmer 141
Chapter 3 Programming with Command Function
2. Connect each direction change point on the
inside line with the matched direction change
point on the outside line using a line.
3. Provide one point (or more points) between the
above two direction change points, and connect
them using a line.
Follow the procedure for curve points specification.
Specify points in pairs on the inside and outside
lines. The lines should be spaced uniformly.
Programming
1. Press .
The work clamp moves to the home position and
the programmer screen is displayed.
2. Move the work clamp with . Press
when the needle point is at point 1 of the
pattern.
The first stitch (point 1) is programmed.
3. Press and .
28
27
26
25
24
23
22
2120
19
18
1
2
3
4
5
6
78
9
10
11
12
13
14 15
16
17
34
33
3231
30
29
To Next Page
