Brother MFC-8220 - Side Cover L;R

CHAPTER 4 DISASSEMBLY AND RE-ASSEMBLY
4-28
3.10 Side Cover L/R
(1) Remove the three bind B M4x12 Taptite screws, and then remove the side cover R.
Fig. 4-48
(2) Remove the four bind B M4x12 Taptite screws, and then remove the side cover L.
Fig. 4-49
Side cover R
Taptite, bind B
M4x12
Side cover L
Taptite, bind B M4x12
Taptite, bind B M4x12
Taptite, bind B M4x12
Taptite, bind B M4x12
Hooks
