MFC-8220
SERVICE MANUAL
2-3
2. UNPACKING
When unpacking the machine, check to see that all of the following components are included
in the carton.
®
®
11
9
5
56
7
11
10
8
3
4
2
1. Control Panel
ADF Document Support
ADF Document Output Support
Telephone Line Cord
Telephone Handset
(U.S.A. / Canada only)
Drum Unit Assembly
(including Toner Cartridge)
Quick Setup Guide
User's Guide
Power Cord
Handset Curled Cord
(U.S.A. / Canada only)
Accessory Order Form
(U.S.A. / Canada only)
CD-ROMs
For Windows
For Macintosh
Test Sheet (U.S.A. only)
2. Telephone Handset
3. ADF Document Output Support
4. Face-down Output Tray Support
Flap with Extension (Support Flap)
5. Manual Feed Tray
6. Paper Tray
7. ADF Document Support
8. Control Panel Cover
9. Face-down Output Tray
10. Front Cover
11.Power Switch
MFC
Fig. 2-1
Carton components may differ from one country to another.
Save all packing materials and the carton.
NOTE:
• The interface cable is not a standard accessory. Please purchase the appropriate
interface cable for the interface you intend to use (Parallel or USB).
• For Parallel use a bi-directional shield interface cable that is IEEE 1284-compliant, and not
longer than 6 feet (2 meters).
• For USB: use a Hi-Speed USB 2.0 interface cable that is not longer than 6 feet (2 meters).
• Please make sure that you use a Hi-Speed USB 2.0 certified cable if your computer uses
a Hi-Speed USB 2.0 interface.
• Even if your computer has a USB 1.1 interface, you can connect the machine.
