Brother MFC-8220 Service Manual

MFC-8220
SERVICE MANUAL
6-3
1.3 Identify the Problem
If you encounter any machine error or problem, first identify it referring to the chart below, then see the appropriate section.
NOTE:
The following troubleshooting sections contain both the actions which users should take or check and the ones which service technicians should
perform.
The machine does
not start printing.
3.1 Paper Loading Problems
3.2 Original Jams
4. Software Setting Problems
Paper jam occurs.
Transmission and
reception of fax
can not be done.
7. Troubleshooting of Telephone/Fax Functions
Other defect.
5. Malfunctions
The machine does not print.
The machine does not work.
The machine does
not load paper.
The control panel
does not work.
6. Troubleshooting of the Control Panel
10. Network Problem
3.3 Paper Jams
Printout is not
correct.
8. Image Defects
9. Incorrect Printout
Printed image has
a problem.
Printed page has a problem.
3.4 Paper Feeding Problems

Brother MFC-8220 Specifications

General

Type	all in one
Tray Capacity	250
Automatic Document Feeder Capacity	30 sheets
Paper Size	letter, legal, a4, b5, a5, b6, a6, exe
Paper Handling	up to 250 sheets
Mono Print Speed	21 pages per minute
Print Resolution Mono	up to 2400 x 600
Maximum Number of Pages Per Month	up to 20, 000
Scanner Type	sheetfed
Scan Resolution	up to 300 x 600
Copier Resolution Mono	up to 600
Fax Function	yes
Cartridges	n/a
Number Of Cartridges	2
Internal Memory	yes
Network	not applicable
Connectivity	parallel, usb 2.0
OS Compatibility	pc: windows 95, 98, 98se, me, nt workstation 4.0, 2000 professional or xp, mac: os 8.6 to 9.2, os x 10.1, 10.2.1 to 10.3 or later, available usb 2.0 or parallel port
Mobile Devices Connection	no

Weight and Dimensions

Height	13.2 inches
Width	17 inches
Net Weight	25.6 pounds
