Brother MFC-8220 Service Manual

MFC-8220
SERVICE MANUAL
1-3
2.4 Copy
Color/Monochrome
Monochrome
Copy Speed
Up to 21cpm (Letter size) (U.S.A., Canada Version only)
Up to 20cpm (A4 size) (Europe Version only)
Multiple Copies
Up to 99 pages
Enlarge/Reduce
25% to 400% (in increments of 1%)
Resolution
600dpi
2.5 Fax
Compatibility
Super G3
Coding System
MH/MR/MMR/JBIG
Modem Speed
33600bps
Original Size
ADF Width: 5.8" to 8.5" (148mm to 216mm)
ADF Height: 3.9" to 14.0" (100mm to 356mm)
Scanning Width
208mm x 291mm
Printing Width
203mm x 291mm
Gray Scale
256 levels
Polling Types
Standard, Confidential, Sequential, Timer
Contrast Control
Automatic/Light/Dark (manual setting)
Resolution
Horizontal: 203 dot/inch (8 dot/mm)
Vertical:
• Standard: 98 line/inch (3.85 line/mm)
• Fine, Photo: 196 line/inch (7.7 line/mm)
• Superfine: 392 line/inch (15.4 line/mm)
One-Touch Dial
32 (16 x 2)
Speed-Dial
300 stations
Automatic Redial
Three times
Auto Answer
0 to 10 rings
Memory
Transmission
Up to 600 pages (Brother #1 Chart)
Out of Paper
Reception
Up to 600 pages (Brother #1 Chart)
2.6 Specifications for Document Feeding System
2.6.1 Specifications for document
Length of document 100mm to 360mm
Width of document 148mm to 216mm
ADF 64 to 90g/m
2
(17 to 24lb)
Weight of document
1 sheet 52 to 90g/m
2
(14 to 24lb)
ADF 0.07mm to 0.12mm
Thickness of document
1 sheet 0.06mm to 0.12mm

Brother MFC-8220 Specifications

General

Type	all in one
Tray Capacity	250
Automatic Document Feeder Capacity	30 sheets
Paper Size	letter, legal, a4, b5, a5, b6, a6, exe
Paper Handling	up to 250 sheets
Mono Print Speed	21 pages per minute
Print Resolution Mono	up to 2400 x 600
Maximum Number of Pages Per Month	up to 20, 000
Scanner Type	sheetfed
Scan Resolution	up to 300 x 600
Copier Resolution Mono	up to 600
Fax Function	yes
Cartridges	n/a
Number Of Cartridges	2
Internal Memory	yes
Network	not applicable
Connectivity	parallel, usb 2.0
OS Compatibility	pc: windows 95, 98, 98se, me, nt workstation 4.0, 2000 professional or xp, mac: os 8.6 to 9.2, os x 10.1, 10.2.1 to 10.3 or later, available usb 2.0 or parallel port
Mobile Devices Connection	no

Weight and Dimensions

Height	13.2 inches
Width	17 inches
Net Weight	25.6 pounds
