MFC-8220
SERVICE MANUAL
A-11
l Selectors 5 and 6: Busy tone detection in automatic sending mode
These selectors determine whether or not the machine automatically disconnects a line upon
detection of a busy tone in automatic sending mode.
Setting selector 6 to "0" ignores a busy tone so that the machine does not disconnect the line.
Setting selectors 5 and 6 to "0" and "1," respectively, makes the machine detect a busy tone
only after dialing and disconnect the line.
Setting both of selectors 5 and 6 to "1" makes the machine detect a busy tone before and
after dialing and then disconnect the line.
l Selector 7: Busy tone detection in automatic receiving mode
This selector determines whether or not the machine automatically disconnects a line upon
detection of a busy tone in automatic receiving mode.
WSW06 (Pause button setting and 2nd dial tone detection)
Selector
No.
Function Setting and Specifications
1
|
3
Pause button setting and 2nd dial
tone detection
No. 1 2 3
0 0 0 : No pause
0 0 1 : 3.5 sec. WAIT
0 1 0 : 7 sec. WAIT
0 1 1 : 10.5 sec. WAIT
1 0 0 : 14 sec. WAIT
1 1 0 : 2nd dial tone detection
only in pulse dialing (DP)
system
1 0 1 : 2nd dial tone detection
1 1 1 : both in DP and push-button
(PB) dialing system
4
|
6
Detection of 2nd dial tone
No. 4 5 6
0 0 0 : 50 ms
0 0 1 : 210 ms
0 1 0 : 500 ms
0 1 1 : 800 ms
1 0 0 : 900 ms
1 0 1 : 1.5 sec.
1 1 0 : 2.0 sec.
1 1 1 : 2.5 sec.
7 No. of 2nd dial tone detection times 0: Once 1: Twice
8
2nd dial tone interrupt detecting
time
0: 30 ms 1: 50 ms
To Next Page
