3. DISASSEMBLY PROCEDURE
3.1 Power Cord
(1) Disconnect the power cord from the machine.
Fig. 4-1
3.2 Drum Unit
(1) Open the front cover ASSY and remove the drum unit.
Fig. 4-2
Power cord
Machine
Drum unit
Front cover ASSY
