MFC-8220
SERVICE MANUAL
4-73
8. HARNESS ROUTING
Toner sensor PCB
Front Front
Front
Front
Front
Front
Front
Front
1
Fan motor 60 unit
2
Fan motor 60 unit LV
3
Laser unit (Polygon motor harness)
4
Toner sensor PCB
Engine PCB ASSY
Engine PCB ASSY
Engine PCB ASSY
Engine PCB ASSY
Fan motor 60 unit
Fan motor 60 unit LV
Laser unit
