Brother MFC-8220 Service Manual

MFC-8220
SERVICE MANUAL
A-47
WSW48 (Function setting 23)
Selector
No.
Function Setting and Specifications
1
2
Not used.
3
|
5
Number of pieces of (scan) key
information registered according to
application (i.e., Number of PCs
that can be registered via Net)
<Available Function>
- PC registration using the Network
TWAIN
0 0 0 : 25 pcs.
0 0 1 : 50 pcs.
0 1 0 : 75 pcs.
0 1 1 : 100 pcs.
1 0 0 : 125 pcs.
1 0 1 : 150 pcs.
1 1 0 : 175 pcs.
1 1 1 : 200 pcs.
6
|
8
Not used.
WSW49 (Function setting 24)
Selector
No.
Function Setting and Specifications
1
2
Size of the RAM Disk when using
PCL/PS
0 0 : None
0 1 : 1 Mbytes
1 0 : 2 Mbytes
1 1 : 4 Mbytes
3
Presence or absence of copy
completion sound
0: Present 1: Absent
4
5
Flag detection time when receiving a
command [*]
0 0 : 150 ms
0 1 : 350 ms
1 0 : 550 ms
1 1 : 750 ms
6
7
Scanning light source WARMUP time
Adjustment
<Models concerned: CCD scanning type>
[*] [BHM-3838] (Not used.)
0 0 : No adjustment
0 1 : 80%
1 0 : 120%
1 1 : 150%
8
Not used.
WSW50
Selector
No.
Function Setting and Specifications
1
|
8
Not used.

Brother MFC-8220 Specifications

General

Type	all in one
Tray Capacity	250
Automatic Document Feeder Capacity	30 sheets
Paper Size	letter, legal, a4, b5, a5, b6, a6, exe
Paper Handling	up to 250 sheets
Mono Print Speed	21 pages per minute
Print Resolution Mono	up to 2400 x 600
Maximum Number of Pages Per Month	up to 20, 000
Scanner Type	sheetfed
Scan Resolution	up to 300 x 600
Copier Resolution Mono	up to 600
Fax Function	yes
Cartridges	n/a
Number Of Cartridges	2
Internal Memory	yes
Network	not applicable
Connectivity	parallel, usb 2.0
OS Compatibility	pc: windows 95, 98, 98se, me, nt workstation 4.0, 2000 professional or xp, mac: os 8.6 to 9.2, os x 10.1, 10.2.1 to 10.3 or later, available usb 2.0 or parallel port
Mobile Devices Connection	no

Weight and Dimensions

Height	13.2 inches
Width	17 inches
Net Weight	25.6 pounds
