Brother MFC-8220 Service Manual

APPENDIX 3 FIRMWARE SWITCHS (WSW)
A-18
WSW12 (Signal detection condition setting)
Selector
No.
Function Setting and Specifications
1
2
Min. OFF time length of calling
signal (Ci)
No. 1 2
0 0 : 1500 ms
0 1 : 500 ms
1 0 : 700 ms
1 1 : 900 ms
3
4
Max. OFF time length of calling
signal (Ci)
No. 3 4
0 0 : 6 sec.
0 1 : 7 sec.
1 0 : 9 sec.
1 1 : 11 sec.
5
6
Detecting time setting
No. 5 6
0 0 : 800 ms
0 1 : 200 ms
1 0 : 250 ms
1 1 : 150 ms
7-8 Not used.
l Selectors 1 through 4: Min. and max. OFF time length of calling signal (Ci)
If the machine detects the OFF state of calling signal (Ci) for a time length which is greater
than the value set by selectors 1 and 2 and less than the value set by selectors 3 and 4, it
interprets the Ci signal as OFF.
l Selectors 5 and 6: Detecting time setting
These selectors set the time length required to make the machine acknowledge itself to be
called. That is, if the machine continuously detects calling signals with the frequency set by
selectors 1 through 4 of WSW14 during the time length set by these selectors 5 and 6, it
acknowledges the call.

Brother MFC-8220 Specifications

General

Type	all in one
Tray Capacity	250
Automatic Document Feeder Capacity	30 sheets
Paper Size	letter, legal, a4, b5, a5, b6, a6, exe
Paper Handling	up to 250 sheets
Mono Print Speed	21 pages per minute
Print Resolution Mono	up to 2400 x 600
Maximum Number of Pages Per Month	up to 20, 000
Scanner Type	sheetfed
Scan Resolution	up to 300 x 600
Copier Resolution Mono	up to 600
Fax Function	yes
Cartridges	n/a
Number Of Cartridges	2
Internal Memory	yes
Network	not applicable
Connectivity	parallel, usb 2.0
OS Compatibility	pc: windows 95, 98, 98se, me, nt workstation 4.0, 2000 professional or xp, mac: os 8.6 to 9.2, os x 10.1, 10.2.1 to 10.3 or later, available usb 2.0 or parallel port
Mobile Devices Connection	no

Weight and Dimensions

Height	13.2 inches
Width	17 inches
Net Weight	25.6 pounds
