Brother MFC-8220 Service Manual

MFC-8220
SERVICE MANUAL
2-1
CHAPTER 2 INSTALLATION AND BASIC OPERATION
1. CONDITIONS REQUIRED FOR INSTALLATION
1.1 Power Supply
• The source voltage must stay within ±10% of the rated voltage shown on the rating plate.
• The power cord, including extensions, should not exceed 5 meters (16.5 feet).
• Do no share the same power circuit with other high-power appliances, particularly an air
conditioner, copier or shredder. If it is unavoidable that you must use the machine with
these appliances, it is recommended that you use an isolation transformer or a high-
frequency noise filter.
• Use a voltage regulator if the power source is not stable.
1.2 Environment
• The machine should be installed near a power outlet, which is easily accessible.
• The room temperature is maintained between 10°C and 32.5°C. The relative humidity is
maintained between 20% and 80%.
• The machine should be used in a well ventilated room.
• Place the machine on a flat, horizontal surface.
• Keep the machine clean. Do not place the machine in a dusty place.
• Do not place the machine where the ventilation hole of the machine is blocked. Keep
approximately 100 mm (4 inches) between the ventilation hole and the wall.
• Do not place the machine where it is exposed to direct sunlight. Use a blind or a heavy
curtain to protect the machine from direct sunlight when the machine is unavoidably set up
near a window.
• Do not place the machine near devices that contain magnets or generate magnetic fields.
• Do not subject the machine to strong physical shocks or vibrations.
• Do not expose the machine to open flames or salty or corrosive gasses.
• Do not place objects on top of the machine.
• Do not place the machine near an air conditioner.
• Keep the machine horizontal when carrying.
• Do not cover the slots in the side cover.

Brother MFC-8220 Specifications

General

Type	all in one
Tray Capacity	250
Automatic Document Feeder Capacity	30 sheets
Paper Size	letter, legal, a4, b5, a5, b6, a6, exe
Paper Handling	up to 250 sheets
Mono Print Speed	21 pages per minute
Print Resolution Mono	up to 2400 x 600
Maximum Number of Pages Per Month	up to 20, 000
Scanner Type	sheetfed
Scan Resolution	up to 300 x 600
Copier Resolution Mono	up to 600
Fax Function	yes
Cartridges	n/a
Number Of Cartridges	2
Internal Memory	yes
Network	not applicable
Connectivity	parallel, usb 2.0
OS Compatibility	pc: windows 95, 98, 98se, me, nt workstation 4.0, 2000 professional or xp, mac: os 8.6 to 9.2, os x 10.1, 10.2.1 to 10.3 or later, available usb 2.0 or parallel port
Mobile Devices Connection	no

Weight and Dimensions

Height	13.2 inches
Width	17 inches
Net Weight	25.6 pounds
