Brother MFC-8220 Service Manual

CHAPTER 7 MAINTENANCE MODE
7-2
2. LIST OF MAINTENANCE MODE FUNCTIONS
Maintenance mode Functions
Function
Code
Function
Reference
Subsection
(Page)
01 EEPROM Parameter Initialization 3.1 (7-4)
02
03
04
05 Printout of Scanning Compensation Data 3.2 (7-5)
06
07
08 ADF* Performance Test 3.3 (7-7)
09 Test Pattern 1 3.4 (7-8)
10 Firmware Switch Setting 3.5.1 (7-9)
11 Printout of Firmware Switch Data 3.5.2 (7-11)
12 Operational Check of LCD 3.6 (7-12)
13
Operational Check of Control Panel PCB
3.7 (7-13)
14
15
16 Receiver Volume Adjustment 3.8 (7-14)
32 Sensor Operational Check 3.9 (7-15)
53 Received Data Transfer Function 3.10 (7-17)
54 Fine Adjustment of Scan Start/End Positions 3.11 (7-19)
55 CIS Scanner Area Setting 3.12 (7-20)
67 Paper Feed and Paper Eject Test 3.13 (7-21)
74 EEPROM Customizing 3.14 (7-22)
80 Display of the Equipment's Log Information 3.15 (7-23)
82 Machine Error Code Indication 3.16 (7-25)
87 Output of Transmission Log to the Telephone Line 3.17 (7-25)
91
EEPROM Parameter Initialization
3.1 (7-4)
99 Exit from the Maintenance Mode
Cancellation of the Memory Security Mode
(No applicable to the Japanese version)
3.18 (7-26)
* ADF: Automatic document feeder
