Brother MFC-8220 Service Manual

MFC-8220
SERVICE MANUAL
A-37
WSW36 (Function setting 14)
Selector
No.
Function Setting and Specifications
1 ECP* mode 0: ON 1: OFF
2
Recovery from inactive PC
interface
0: Disabled 1: Enabled
3 PC power-off recognition time 0: Normal 1: Long
4 Not used.
5 Escape from phase C 0: Yes 1: No
6
|
8
Lower limit of frequency to be
ignored after detection of calling
signals (Ci)
No. 6 7 8
0 0 0 : 0 (Not ignored)
0 0 1 : 4 (448 Hz)
0 1 0 : 8 (244 Hz)
0 1 1 : 12 (162 Hz)
1 0 0 : 16 (122 Hz)
1 0 1 : 20 (97 Hz)
1 1 0 : 24 (81 Hz)
1 1 1 : 28 (69 Hz)
*ECP (Enhanced Capabilities Port)
z Selector 1: ECP mode
The ECP mode enhances the normal bidirectional communications between the machine
and the connected PC for higher transmission speed.
z Selector 2: Recovery from inactive PC interface
If the machine recognizes via the STB signal line that the connected PC is powered off, it will
turn the PC interface outputs Low to protect the PC from hazards that could be caused by
weak electric current accidentally flown from the machine.
This selector determines whether the machine should recover from the inactive PC interface
to normal interfacing state upon receipt of data from the PC.
z Selector 3: PC power-off recognition time
This selector sets the time length from when the machine detects the PC powered off until it
recognizes the detected state as power-off.
If selector 2 is set to "0," it is recommended that selector 3 be set to "1": otherwise, the
machine may mistakenly detect PC powered off.
z Selector 5: Escape from phase C
This selector determines whether or not the machine will escape from phase C when it
detects an RTC (Return to Control) in non-ECM mode or an RCP (Return to Control Partial
page) in ECM mode.
z Selectors 6 through 8: Lower limit of frequency to be ignored after detection of calling signals
(Ci)
At the start of reception, if the machine detects the frequency of calling signals (Ci) specified
by selectors 1 through 4 of WSW14, it will start the ringer sounding. When doing so, the
machine may fail to detect the calling signals normally due to noises superimposed at the
time of reception. To prevent it, use selectors 6 through 8 of WSW36.
If the machine detects higher frequencies than the lower limit specified by these selectors, it
will regard them as noise and interpret that detecting state as being normal, allowing the
ringer to keep sounding (until the machine starts automatic reception of FAX data if in the
FAX mode, according to the preset number of ringers).

Brother MFC-8220 Specifications

General

Type	all in one
Tray Capacity	250
Automatic Document Feeder Capacity	30 sheets
Paper Size	letter, legal, a4, b5, a5, b6, a6, exe
Paper Handling	up to 250 sheets
Mono Print Speed	21 pages per minute
Print Resolution Mono	up to 2400 x 600
Maximum Number of Pages Per Month	up to 20, 000
Scanner Type	sheetfed
Scan Resolution	up to 300 x 600
Copier Resolution Mono	up to 600
Fax Function	yes
Cartridges	n/a
Number Of Cartridges	2
Internal Memory	yes
Network	not applicable
Connectivity	parallel, usb 2.0
OS Compatibility	pc: windows 95, 98, 98se, me, nt workstation 4.0, 2000 professional or xp, mac: os 8.6 to 9.2, os x 10.1, 10.2.1 to 10.3 or later, available usb 2.0 or parallel port
Mobile Devices Connection	no

Weight and Dimensions

Height	13.2 inches
Width	17 inches
Net Weight	25.6 pounds
