MFC-8220
SERVICE MANUAL
4-71
7. LUBRICATION
PG4
PG4
PG4
PG4
PG4
PG4
PG4
PG4
PG4
PG4
PG4
PG4
PG4
PG4
PG4
BG4
EM3
BG4
BG4
BG4
EM3
Shaft idle gear 16
Idle gear 16A
Shaft idle gear 16
Idle gear 16A
Drive unit
Gear 58/88
Pendulum gear 22
Pendulum gear 22
Gear, 40/54Y
Gear 45 arm F/R
Gear 17 planetary
Gear 20 center F/R
Flame L
* PG4: Molykote PG-662Y 4 mm dia. ball
BG4: Grease BG999 4 mm dia. ball
EM3: Molykote EM-D110 3 mm dia. ball
Gear 58/88
Fuser drive gear
Gear 25/130
Gear 25/130
Fuser drive gear
