CHAPTER 4 DISASSEMBLY AND RE-ASSEMBLY
4-34
3.12 Front Cover ASSY
(1) Release the link.
(2) Remove the front cover ASSY.
Fig. 4-60
Frame
Front cover ASSY
Link
