MFC-8220
SERVICE MANUAL
A-9
WSW03 (PABX* mode setting)
Selector
No.
Function Setting and Specifications
1
CNG detection when sharing a
modular wall socket with a
telephone
0: A 1: B
2
|
4
Not used.
5
CNG detection when sharing a
modular wall socket with a
telephone
0: A 1: B
6
|
8
Not used.
* PABX: Private automatic branch exchange
NOTE:
Selectors 2 through 4, 6 and 8 are not applicable where no PABX is installed.
l Selectors 1 and 5: CNG detection when sharing a modular wall socket with a telephone
These selectors determine whether or not the machine detects a CNG signal when a line is
connected to a telephone sharing a modular wall socket with the machine. Upon detection of
CNG signals by the number of cycles specified by these selectors, the machine interprets
CNG as an effective signal and then starts FAX reception.
Selector
No. 1 No. 5
Cycle
0 (A) 0 (A)
0 (A) 1 (B)
1 (B) 0 (A)
1 (B) 1 (B)
0.5 cycle
1.0 cycle
1.5 cycles
2.0 cycles
WSW04 (TRANSFER facility setting)
Selector
No.
Function Setting and Specifications
1
|
6
Not used.
7
8
Break time length for flash
function
No. 7 8
0 0 : 80 ms
0 1 : 110 ms
1 0 : 250 ms
1 1 : 500 ms
NOTE:
Selectors 5 through 8 are not applicable in those countries where no transfer facility is
supported.
l Selectors 7 and 8: Break time length for flash function
These selectors set the break time length.
This setting is effective only when the flash function is selected for the R key by using the
function switch.
To Next Page
